1501H/MOLEX1.5
额定电流：1A AC，DC
额定电压：100V AC，DC
温度范围：-25℃～+85℃
接触电阻：最大20mΩ
绝缘电阻：最小500mΩ
耐受电压：500V AC/分钟
适用线号：AWG#26-#28
Current rating: 1A AC,DC
Voltage rating: 100V AC, DC
Temperature range: -25 ℃ to+85 ℃
Contact resistance: maximum 20m Ω
Insulation resistance: minimum 500m Ω
Withstand voltage: 500V AC/min
Applicable wire: AWG#26-#28
